Compaq DA-10832 - Manual (Page 10)

QuickSpecs
Compaq iPAQ Desktop
DA-10832 North America — Version 8 — September 14, 2001 10
Technical Specifications
System Unit Dimensions (HxWxD) 13.8 x 5.4 x 10.43 in/34.9 x 13.8 x 26.4 cm
Weight 10.3lbs/4.68kg (without MultiBay device, keyboard, or mouse)
Power Supply Operating Voltage Range
Rated Voltage Range
Rated Line Frequency
Rated Input Current
Maximum Rated Power
90 to 132 VAC/180 to 264 VAC
100 to127 VAC/200 to 240 VAC
47-63 Hz
4A / 2A
90W
Temperature Operating 50° to 95°F/10° to 35°C
Non-operating –4° to 140°F/–20° to 60°C
Humidity Operating 20% to 80%
Non-operating 10% to 90%
Maximum Altitude Operating 10,000 ft/3,048 m
Non-operating 30,000 ft/9,144 m
Maximum Rate of Change 1500 feet per minute/457 meters per minute
Memory 64 MB or 128MB SDRAM standard
Dimensions (HxWxD) 1.4 x 18.3 x 6.3 in/36 x 465 x160 mm Compaq Easy
Access Keyboard
Weight Approximately 2 lbs/0.9 kg
Electrical Operating Voltage + 5VDC ± 5%
Power Consumption 50 mA maximum (with 3 LEDs on)
System Interface PS/2 mini-din connector
ESD CE level 4, 15 kV air discharge
EMI-RFI Conforms to FCC rules for a Class B computing
device
PC98 Functionally compliant
Mechanical Languages 30 + available
Keycaps Low-profile design
Switch Actuation 55 g nominal peak force with tactile feedback
Switch Life 20 million keystrokes (using Hasco modified tester)
Switch Type Contamination resistant membrane
Key Leveling Mechanism For all double wide and greater length keys
Cable Length 6 ft/1.8 m
PC98-99 Mechanically compliant
Acoustics 50 dBA maximum sound pressure level
Environmental Operating Temperature 50 ° to 122 ° F/10 ° to 50 ° C
Non-operating Temperature − 22 ° to 140 ° F/ − 30 ° to 60 ° C
Operating Humidity 10% to 90% (non condensing at ambient)
Non-operating Humidity 20% to 80% (non condensing at ambient)
Operating Shock 40 g, 6 surfaces
Non-operating Shock 80 g, 6 surfaces
Operating Vibration 2 g peak acceleration
Non-operating Vibration 4 g peak acceleration
