Zipper's Performance Products, 6655-A Amberton Dr., Elkridge, MD 21075 Internal Ignition Part No. 317-105
Tel: (410)-579-2828 Fax: (410)-579-2835
www.zippersperformance.com 7/2006
Page 9
The optional USB interface cable connects to
the brown tachometer wire as shown in Figures 4 and
5. The cable also has a ground clip that must be
connected to frame or engine ground. The other end of
the cable connects to the USB port on a laptop PC.
KICK START APPLICATIONS
317-105 units are preset at the factory with a
two revolution cranking delay that is optimum for
electric start applications. This cranking delay
precludes kick starting. 317-105 units manufactured
starting January, 2006 can be programmed for kick
start mode. PC Link Evo software and the USB
interface cable are required to program kick start
mode.
USE OF VOES INPUT FOR RETARD
The 317-105 module can be programmed to
allow alternate usage of the purple/white VOES wire as
a retard input. If this feature is enabled, the unit will
retard timing up to 10 degrees when the purple/white
wire is grounded. This retard feature is useful for
turbocharger or nitrous oxide injection applications. PC
Link Evo software and the USB interface cable are
required to program the retard feature.
TROUBLESHOOTING FLOWCHART
Follow the troubleshooting flowchart shown on
the next page. Experience has shown that most units
returned for warranty are OK and another problem,
such as a defective coil, is later identified.
