UI3
Universal input no.3 configuration
Default value = None

(None): No function will be associated with the input

(COC/NH) Change over dry contact. Normally Heat: Used for hot / cold water or
air change over switching in 2 pipe systems.
Contact closed = Cold water or air present
Contact opened = Hot water or air present
Only used and valid if system is setup as 2 pipes. Parameter ( Pipe No ) set as 2
pipes.

(COC/NC) Change over dry contact. Normally Cool: Used for hot / cold water or
air change over switching in 2 pipe systems.
Contact closed = Hot water present
Contact opened = Cold water present
Only used and valid if system is setup as 2 pipes. Parameter (Pipe No ) set as 2
pipes.

(COS) Change over analog sensor: Used for hot / cold water or air change over
switching in 2 pipe systems.
Only used and valid if system is setup as 2 pipes. Parameter (Pipe No ) set as 2
pipes.
If water temperature is > 78 °F = Hot water present
If water temperature is < 75 °F = Cold water present

(SS) Supply air sensor monitoring: Used for supply air temperature monitoring.
Only used for network reporting of the supply air temperature. Has no internal
function in the thermostat.

MenuScro
Menu scroll
Default value = On = Scroll active

Removes the scrolling display and only present the room temperature/humidity to the user.
With this option enabled, no status is given of mode, schedule and outdoor temperature.

On = Scroll active

Off = Scroll not active

AutoMode
Enables Auto menu for Mode
button
Default value = Off

Enables Auto function for the mode button
For sequences 2, 4 & 5 only
On = Auto active (Off-Cool-Heat-Auto)
Off = auto not active (Off-Cool-Heat)

C or F
Sets scale of the thermostat
Default value = °F

°F for Fahrenheit scale
°C for Celsius scale
On hotel models, this sets the default value when the thermostat powers up

%RH disp
Local %RH Display

Default value = OFF
Models with Humidity sensor only
VT735xX5x00(x) models only

RH models only
Enables the display of humidity below the room temperature on the display

ON
= Display %RH
OFF = No display of %RH

Lockout
Keypad lockout levels
Default value = 0 No lock

Level

Occupied temperature

setpoints

System mode setting

Fan mode setting

Unoccupied Override

0

Yes access

Yes access

Yes access

Yes access

1 Yes

access

Yes access

Yes access

No access

2

Yes access

No access

No access

Yes access

3

Yes access

No access

No access

No access

4

No access

No access

No access

Yes access

5

No access

No access

No access

No access

Pipe No

System type installation
Number of pipes
Default is: 4.0 Pipes

Defines the type of system installed

2.0 Pipes, will limit the number of sequences of operation available from 0 to 3
Will enable heat/cool operation from the same output ( refer to wiring diagram )

4.0 Pipes, can access all the sequences of operation from 0 to 5
Will enable heat/cool operation from different output ( refer to wiring diagram )
