12
Get From
Thermostat Get From another
device configuration utility
Default value = 0
Range is: 0 to 254 Conditional parameter to Wireless models (VT730xX1000W)
This parameter will only appear when a wireless network adapter is present. If
the thermostat is installed as a stand-alone unit or with a BACnet or Echelon
adapter, this parameter will not be used or displayed
This function is used when you want to copy all the configuration parameters
automatically from another thermostat of the SAME model communicating on the
SAME network.
Configuration parameters copied from another device during this process are
marked below with an (*).
The thermostat will begin querying the network 30 seconds after this parameter is
given an address to query. If the device queried is not online yet, the thermostat
will continue querying the specified device for its properties every 30 seconds
until it comes on line and gets the requested information. If the specified address
is unused and does not exist, the thermostat repeat its query every 30 seconds
indefinitely.
When the thermostat receives the configuration information, the query for
configuration is disabled. The only way to re-enable the request for the
configuration properties is by changing the actual address of the queried device
to another value.
The default value of 0 is NOT a valid address and disables this function.
If the specified thermostat is of a different model, the query will be disabled
automatically. The only way to re-enable the request for the configuration
properties is by changing the actual address of the queried device to another
value and to use a valid address used by a thermostat of the SAME model
number.
BI1 *
Binary input no.1 configuration
Default value = None (None): No function will be associated with the input
(Rem NSB): remote NSB timer clock input. The scheduling will now be set as per
the binary input. It provides low cost setback operation via a dry contact
Contact opened = Occupied
Contact closed = Unoccupied
(Motion NO)*: remote NSB using a motion detector. The occupancy will now be
set as per the binary input.
Contact opened = Unoccupied. When the contact closes momentarily, the
thermostat goes into occupied mode for the time specified by the ToccTime timer.
The timer can reset at the end of its cycle if new movements are detected in the
area.
(Motion NC)*: remote NSB using a motion detector. The occupancy will now be
set as per the binary input.
Contact closed = Unoccupied. When the contact opens momentarily, the
thermostat goes into occupied mode for the time specified by the ToccTime timer.
The timer can reset at the end of its cycle if new movements are detected in the
area.
(Window) EMS: Forces the system to disable any current heating or cooling
action by the thermostat. The mode stays the same and the current setpoints are
the same Occupied setpoints. Only the outputs are disabled. There is a
Door/Window alarm displayed on the thermostat to indicate to the local tenant
that the door/window needs to be closed for cooling or heating to resume.
* these settings will disable the local override function on the thermostat.
