Page 55
Note: The active pressure transducer
(VSP 3000) is not displayed in the sta-
tus line of the controller display!
When operating the CVC 3000 with the
external VSP 3000 pressure transduc-
er,
vacuum control is not possible in
the
”Auto mode” and ” VACUULAN”
functions.
1.0
x
10
3
mbar
”Pump down” function:
”Minimum” is adjustable in a range of 1x10
-3
Torr to 7.5x10
2
Torr (1x10
-3
mbar to 1x10
3
mbar) or can be set to ”Off”.
”VAC control” function:
”Set vacuum” (factory set 7.5x10
2
Torr), ”Hysteresis” and ”Maximum” are
adjustable in a range of 7.5x10
2
Torr to 1x10
-3
Torr (1x10
3
mbar to 1x10
-3
mbar).
Set vacuum in Torr
1-9 x 10
1
1-9 x 10
0
1-9 x 10
-1
1-9 x 10
-2
1-9 x 10
-3
Hysteresis in Torr
(suggested values)
1 x 10
1
1 x 10
0
1 x 10
-1
1 x 10
-2
1 x 10
-3
Adjustment of the set vacuum during vacuum control:
Fine tuning:
The set vacuum can be fine-adjusted by turning the selection knob while
process is running.
+
Turn the selection knob.
+
A full turn causes a change of the set vacuum of 1.2 decades.
+
Turning the knob one detent causes a change of the set vacuum of
1/10 decade.
Serial Interface:
Command IN_PV: The vacuum value is given as X.XXE±X.
Command OUT_SP or IN_SP: The vacuum value is given as XE±X.
