Assembly of a vacuum system
+
Assemble vacuum connection lines between CVC 3000 controller or
an external pressure transducer, vacuum pump (NT VARIO / VARIO-B
pump or diaphragm pump with in-line valve or Vacuum-Management-
System) and vacuum application.
+
Assemble electrical connections.
+
Connect coolant if necessary.
Vacuum for filtration and suction
+
Select ” Pump down” function.
+
If necessary, set value for ”Speed” (high or low pumping speed; only
with NT VARIO / VARIO-B pump). Reduce the speed in case of fast
sedimentation (formation of a filter cake).
+
Set ”Minimum” to a value which provides adequate suction but does
not lead to evaporation of the solvent.
+
Start process by pressing ”START/STOP” key.
alternatively:
+
Select ” Vac control” function.
+
Set ”Set vacuum” (and ”Hysteresis”, if necessary; only without NT
VARIO / VARIO-B pump) to a value which does not lead to evapora-
tion of the solvent.
+
If necessary, set value for ”Speed” (high or low pumping speed; only
with NT VARIO / VARIO-B pump). Reduce the speed in case of fast
sedimentation (formation of a filter cake).
+
Set ”Maximum” pressure setting so that pump will switch off at the end
of the filtration process, or in the event that a filter cake cracks, leading
to a sudden pressure increase.
+
Start process by pressing ”START/STOP” key.
+
Tip for filtration: Adjust preset pressure to a value well above the
boiling pressure of the solvent (e.g., for water >>15 Torr (20 mbar)).
Set the maximum pressure to e.g., 375 Torr (500 mbar). Once the fil-
tration has finished, the pressure increases and the pump is switched
off automatically.
Application examples
