Pump parts
Position Bezeichnung
1 Inlet
2 Outlet
3 Gas ballast valve
4 ON/OFF switch
5 Mains connection
6 Handle
7 Pump rating plate
8 Controller CVC 3000
9 Catchpot
10 Exhaust waste vapour condenser
Position Bezeichnung
11 Overpressure safety relief device
12 Coolant inlet
13 Coolant outlet
14 Flow control diaphragm
15 In-line valve
16 Valve block
17 Distribution head
18 Fan
PC 510 NT
6
1
3
7
10
11
9
4
15
8
5
2
12
13
18
17
