Appendix
Connector pinouts
Inputs Right Output Center Output Left Output
(Right to Left) (Right to Left) (Right to Left) (Right to Left)
Left Channel + Low Band + Low Band + Low Band +
Left Channel – Low Band – Low Band – Low Band –
Left Channel E Low Band E Low Band E Low Band E
Center Channel + Mid Band + Mid Band + Mid Band +
Center Channel – Mid Band – Mid Band – Mid Band –
Center Channel E Mid Band E Mid Band E Mid Band E
Right Channel + High Band + High Band + High Band +
Right Channel – High Band – High Band – High Band –
Right Channel E High Band E High Band E High Band E
Chassis Gnd Chassis Gnd Chassis Gnd Chassis Gnd
Crossover List
Speaker Type Switch Switch Bypass
Manufacturer A B Switch
EAW MC4953/MC4973 2 0 Off
EV 3 Way Variplex 3 0 Off
JBL 3 Way 5672/5674 5 0 Off
