Expansion Slots Expansion Slots Expansion Slots Expansion Slots
Expansion Expansion Expansion Expansion
Slot # Slot # Slot # Slot #
Technology Technology Technology Technology Width Width Width Width Connector Connector Connector Connector
Width Width Width Width *
Bus Bus Bus Bus
Number Number Number Number **
Form Factor Form Factor Form Factor Form Factor Notes Notes Notes Notes
1 PCI-X 64-bit N/A 42h FH/HL 100MHz
2 PCI-X 64-bit N/A 42h FH/FL 100MHz
3 PCI Express x4 x8 49h FH/FL
4 PCI Express x4 x8 4Ch FH/FL
5 PCI Express x8 x16 46h FH/FL
6 PCI Express x4 x8 4Fh FH/FL
7 PCI Express x8 x16 02h FH/FL
8 PCI Express x8 x16 05h FH/FL
9 PCI Express x4 x8 08h FH/HL Reserved for
storage
controller
* Default bus assignment. Inserting cards with PCI bridges may alter the actual bus assignment number.
** Slots are enumerated differently based on OS. MS OS's enumerate from lowest to highest Device ID
by bus (starting with the lowest bus).
FH = Full height; FL = Full length; HL = half-length; LP = Low profile.
Manageability Manageability Manageability Manageability Integrated Lights-Out 2 (iLO 2) Standard Management (ASIC on the System Board)
Storage Controllers Storage Controllers Storage Controllers Storage Controllers
One of the following
depending on Model
HP Smart Array P400/256MB Controller (in a PCI-Express slot)
NOTE: NOTE: NOTE: NOTE: Standard on 2.0GHz and 2.2GHz models.
HP Smart Array P400/512MB BBWC Controller (in a PCI-Express slot)
NOTE: NOTE: NOTE: NOTE: Standard on 2.4GHz, 2.6GHz, 2.8GHz, and 3.0GHz models.
Storage Data Protection Storage Data Protection Storage Data Protection Storage Data Protection The Battery-Backed Write Cache (BBWC) Enabler for the Smart Array P400 Controller protects up to
512-MB write cache memory from hard boot, power, controller, or system board failures.
Standard on all HP ProLiant DL585 G2 Models
Battery charge/life: Up to 72 hours/3 years
Transportable data protection
Increases overall controller performance
NOTE: NOTE: NOTE: NOTE: Safely transport your write cache data to another HP ProLiant DL585 G2 in the data center by
removing the BBWC Enabler and Smart Array P400 Controller Memory Module simultaneously
(connected by short cable).
