• The trailer axles scale indicator will display: the total weight placed on
platforms 3A and 3B, the total weight placed on platforms 3C and 3D, and the
total of all weights placed on platforms 3A through 3D. The wireless remote
will display the total of all weights placed on platforms 3A through 3D.
11. ANCHOR THE SYSTEM AND MOUNT THE DISPLAYS
After rechecking the platforms for corner-to-corner rocking and making any needed
adjustments, anchor the platforms using the provided ¾” anchor bolts. Weighing
platform anchor locations are under the access panels. Spacer platforms have anchor
tabs.
Anchor the digital indicator stands using the provided ½” anchor bolts. Mount the
indicators to the anchored stands.
Mount the wireless scoreboard remote displays as required.
