Assembly Guide
Axle Weighing Truck Scale
6
Locate the four 50 ft. cables with connectors labeled 1A, 2A, 3A and 3C.
ATTACH THE CABLES TO THE LEFT SIDE WEIGHING PLATFORMS
Cables 1A, 2A, 3A and 3C connect to the Left Side Weighing Platforms, and run
directly to the digital indicators.
• Attach the long cable connector 1A to the matching weighing platform
connector 1A.
• Attach the long cable connector 2A to the matching weighing platform
connector 2A.
• Attach the long cable connector 3A to the matching weighing platform
connector 3A.
• Attach the long cable connector 3C to the matching weighing platform
connector 3C.
9. CONNECT WEIGHING PLATFORM CABLES TO THE DIGITAL
INDICATORS
Refer to the System Setup Diagram on page 8 when connecting the cables.
Do not mount the digital indicators on stands at this point.
Indicators mounted on stands that have not been anchored are prone
to severe damage from being knocked over. Place the indicators on a
bench or cart for initial connecting and testing of the system.
Before plugging in the digital indicators to 110VAC, connect all weighing platform
cables to the digital indicators, being sure to match up all of the connector labels, i.e.,
the 1A cable connects to the 1A connector on the Steering Axle digital indicator.
11. POWER ON AND TEST THE SYSTEM
Plug the digital indicators in to 110VAC. Power on the digital indicators by pressing the
red “ON” key and allow the system to warm up several seconds.
Plug in the wireless scoreboard remote displays to 110 VAC.
After a few moments, all displays should read “0” lb. If not, press the “ZERO” key (not
the number 0 key). If displays do not read “0” lb, recheck all connections. Be sure to
power off the indicators before making any changes to the connections. If for any
reason the displays will not read “0” lb, contact Triner Scale technical support toll free
at (800) 238-0152, Mon-Fri 8:00 – 4:30 CST.
With all displays indicating “0” lb, place at least 200 lb of weight on each of the eight
weighing platforms.
• The steering axle scale indicator and wireless remote will display the total
weight placed on platforms 1A and 1B.
•
The drive axles scale indicator and wireless remote will display the total weight
placed on platforms 2A and 2B.
IMPORTANT
