Toa BC-5000-2 User Manual

Page 6

Step 4. Turn off the power switch of the unit to be charged, then load the WB-2000 battery in the unit.

Note
The battery cannot be correctly charged if the power switch is ON.

Step 5. Insert the unit fully into the charger's rechargeable unit receptacle directly or with use of the mounting

adapter.

[Inserting the WM-5225 or WM-5265]
Insert it into the hole in the mounting adapter.

[Inserting the WM-5325 or WT-5100]
Insert it directly into the charger's receptacle without using the adapter.

Mounting adapter

Charger

Removing the mounting adapter

Hold up the adapter pressing on its both sides.

Charging takes about 3 hours, after which the full-charge indicator lights green.

Step 6. Turn off the charger's power after charging is complete.

Notes
• The fully-charged unit becomes warm, however this is not a failure.
• Hold the charger when detaching the unit from the charger.
