38
11.9. FS-7000RM Remote Microphone
11.10. FS-7010RM Remote Microphone Extension
24 V DC (operating range: 20 – 30 V DC) (supplied from RJ45 connector or
power input jack),
Usable power input plug: 5.5 mm outer diameter, 2.1 mm inner diameter,and 9.5
mm long.
90 mA
0 dB*, 600Ω, balanced, RJ45 connector
–40 dB*, 2.2 kΩ, unbalanced, mini jack, phantom powering
Under 1%
100 – 20,000 Hz
Over 60 dB
10 individual zones + all-zone call or 10 group zones + all-zone call
(when optional FS-7000GM is connected)
(individual zones expandable to up to 50 zones using optional FS-7010RM)
All-zone selection key, Chime key, Broadcast reset key, Zone selection keys,
Talk key
Power indicator, Fault indicator, Busy indicator, All-zone call indicator,
Zone indicators
0°C to +40°C
Under 90% RH (no condensation)
ABS resin, blueish gray
190 (w) x 76.5 (h) x 215 (d) mm (gooseneck microphone excluded)
900 g
Power Source
Current Consumption
Output
External Microphone
Input
Distortion
Frequency Response
S/N Ratio
Output Control
Operating Section
Display Section
Operating Temperature
Operating Humidity
Finish
Dimensions
Weight
* 0 dB = 1 V
Note: The design and specifications are subject to change without notice for improvement.
• Accessory
Connection cable (3 m) .............................. 1
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Connection cable (8 pins, 8 cm) ................ 1
Linkage bracket A ...................................... 2 Linkage bracket B ...................................... 1
Tapping screw 3 x 8 ................................. 12
Supplied from the FS-7000RM
15 mA (increment in FS-7000RM's current consumption)
Zone selection keys
Zone indicators
0°C to +40°C
Under 90% RH (no condensation)
ABS resin, blueish gray
110 (w) x 76.5 (h) x 215 (d) mm
350 g Power Source
Current Consumption
Operating Section
Display Section
Operating Temperature
Operating Humidity
Finish
Dimensions
Weight
