6. INSTALLATION
Keep the unit's all sides over 10 cm away from objects that may obstruct air flow to prevent the unit's internal
temperature rise.
7. RACK MOUNTING
To mount the unit in a standard 19" equipment rack, use the optional MB-25B Rack Mounting Bracket.
Attach the MB-25B to the unit using the supplied 4 screws. When using other screws, each screw must be
shorter than 16 mm.
MB-25B
M4 x 16 Machine screw included in MB-25B
Amplifiers
PF-013B (optional)
Note
Use the optional PF-013B Perforated Panels to provide
sufficient ventilation when mounting 2 or more units in an
equipment rack.
