FieldPilot
®
iNstAllAtioN
If there are questions concerning the installation of the FieldPilot system on this vehicle, or due to
the changes in component specifications the parts supplied in the kit are not exactly as presented
in this document, please contact your dealer or TeeJet Customer service representative for
clarification before installation. TeeJet Technologies is not responsible for misuse or incorrect installation of
the system.
NOTE: BE VERY CAREFUL TO ABSOLUTELY SECURE ALL CABLES AND HOSES SO THAT THEY
DON’T INTERFERE WITH THE MANY MOVING PARTS OF THE MACHINE!
Overview of the Machine
• The FieldPilot valve will mount on the right side of the machine.
• The EF oil from the priority valve will route through the FieldPilot valve.
• Priority valve is located inside the left frame rail behind the front axel.
• The steering and tank connections will be at the orbital.
• The AGM will mount on the rear half of the machine.
NOTE: All references to left and right are stated as if the user is seated in the driver’s seat.
Figure 1-3: Overview of the Machine
Gps
Fieldpilot
Valve
orbital
possible AGM location
possible AGM location
priority
Valve
