7
FieldPilot ®
98-05145 R1
installation
If there are questions concerning the installation of the FieldPilot system on this vehicle, or due to the
changes in component specifications the parts supplied in the kit are not exactly as presented in this
document, please contact your dealer or TeeJet Customer service representative for clarification
before installation. TeeJet Technologies is not responsible for misuse or incorrect installation of the system.
NOTE: BE VERY CAREFUL TO ABSOLUTELY SECURE ALL CABLES AND HOSES SO THAT THEY DON’T
INTERFERE WITH THE MANY MOVING PARTS OF THE MACHINE!
Due to difficulties accessing all the ports at the John Deere Orbital valve, most hydraulic connections are made on
the rear of the John Deere 8X20 at the Selective Control Valve (SCV) stack. The A & B steering outputs from the
FieldPilot valve are routed to the John Deere orbital valve located just forward of the cab.
overview of the Machine
• The FieldPilot valve will mount at the rear of the machine.
• The Tank, Pressure, and LS connections will be to the Selective Control Valve (SCV) stack at the rear of the
machine.
• The GPS antenna will mount on the hood.
• The steering hose connections will be to the John Deere orbital valve just under the front left of the cab.
NOTE: All references to left and right are stated as if the user is seated in the driver’s seat.
Figure 1-3: Overview of the Machine
Gps
Fieldpilot
Valve
selective Control
Valve (sCV) stack
steering Hose
Connections
