4. PrePare the rear scV stack
Remove the plugs or test ports from the LS, T, and P ports of the rear SCV stack. Insert
(R)
in the LS port and
then insert
(S)
with the threaded end up. Next install adapters
(Q)
in the LS, T, & P ports of the SCV stack.
NOTE: If adapters
(Q)
have a metal washer it must be removed first.
Figure 1-7: Prepare The Rear SCV Stack
R
Q
s
threaded end
insert R & s
