FieldPilot ®
Kit CoNteNts
Unpack the installation kit and identify the required parts.
Item Part Number Description Quantity
A 32-04040 Switch, Engage/Disengage ......................................................................................1
B 45-05396 Power Cable, Cab Access .......................................................................................1
C 45-05626 Cable, Main Matrix Console .....................................................................................1
D 45-05801 Cable, John Deere - EHPS to TeeJet ......................................................................1
E 45-07718 Harness, SCM, Short ...............................................................................................1
F 45-08101 Terminator, CAN Male, WP ......................................................................................1
G 60-04141 Screw, Socket Head Cap, M5-0.8 x 25mm SST ......................................................2
H 60-05042 Spacer, 3/8” OD, 1/2” Long, #12 Screw, Aluminum .................................................2
I 78-05080 Interface, EHPS to SCM ..........................................................................................1
J 78-05083 Interface, John Deere - Steering Sensor to SCM (disengage) ................................1
K 78-05085 Interface, John Deere Wheel Sensor 1, John Deere 10/20/30/R-Series .................1
L 78-05086 Interface, John Deere Wheel Sensor 2, John Deere 10/20/30/R-Series .................1
M 78-05087 Interface, John Deere Angle Sensor, John Deere 10/20/30 Series .........................1
M 78-05084 Interface, John Deere Angle Sensor, John Deere R-Series 8 POS .........................1
N 78-08061 Steering Control , Module, FieldPilot IV ..................................................................1
O 90-50013 Cable Tie Kit, 15 ......................................................................................................1
P 91-07013 Kit, Dust Caps, John Deere EPHS 8xxx Series .......................................................1
Q 98-05227 Installation Manual John Deere w/Factory Valve .....................................................1
NOTE: Which (M) is included depend upon which kit was ordered.
