FieldPilot ®
11. recOMMended electrOnics installatiOn
The Steering Control Module (SCM) should be mounted securely to the floor of the cab as far forward in the
cab as possible.
NOTE: There are wires under the floor mat so be sure that the SCM mounting does not damage them.
The control console can be mounted to the operator’s preference. The GPS antenna should be mounted
near the nose of the vehicle on a metal surface of at least 4” square.
The Articulated Gyro Module (AGM) should be mounted towards the rear of the vehicle on a flat surface that
is horizontal to the ground. Plug the CAN extension cable to the AGM Harness (45-07716) as well as the
CAN terminator. Route the other end of the CAN extension cable towards the cab and connect to the CAN on
the SCM harness.
Figure 1-14: Recommended Electronics Installation
sCM
Console
Gps
AGM
