FieldPilot ®
6. install Pressure hOse and adaPter
Disconnect the pressure hose from the Priority Valve as shown and install run tee (S) . Reconnect the
original pressure hose to the run of the tee. Then connect hose (N) from the branch of run tee (S) to the P
port on the FieldPilot valve.
Figure 1-9: Install Pressure Hose and Adapter
N
s
pressure Hose
N
