Fieldpilot, Installation of engage/disengage switch – TeeJet FieldPilot Install Case MX Magnum w/Factory Valve User Manual
Page 9
www.teejet.com
9
FieldPilot
®
3. INSTALLATION Of ENgAgE/DISENgAgE SwITCh
Connect item
(A)
to the connector on the SCM harness labeled Remote Engage/Disengage. Install the push
button in a location that is easily accessible during operation of the machine. This switch
(A)
is not required
if the optional foot switch 32-04020 is used.
Figure 1-4: Engage/Disengage Switch
