FieldPilot ®
1. PrePare the FieldPilOt ValVe
Install adapters (W) in the A, B, ports of the FieldPilot Valve and then attach 90° adapters (V) to adapters
(W) . Install adapter (Y) in the LS port and adapter (X) in the T port. Then install adapter (R) in the P port
and attach adapter (Q) to adapter (R) .
Figure 1-4: Prepare the FieldPilot Valve
V
W
V
W
X
r
Complete
Q
Y
