System Management
5.5 Monitoring
Table 5–3 New RTR Version 3 Monitor Pictures
Picture Description
accfail Shows most recent links on which a connection attempt was declined.
acp2app Shows RTRACP-to-application message counts.
app2acp Shows application-to-RTRACP message counts.
broadcast Shows information about RTR user events by process.
connect Renamed to netstat.
connects Shows connection status summary.
dtx Shows distributed transaction calls status.
dtxrec Shows distributed transaction recovery status and journal states.
event Shows event routing data by facility.
frontend Shows frontend status and counts by node and facility, including frontend state,
current router, reject status, retry count, and quorum rejects.
group Shows server and transaction concurrency by partition.
ipc Shows interprocess communication counts for messages and connects.
jcalls Displays counts of successful (success), failed (fail), and total journal calls for local
and remote journals.
netstat Shows link counters relating to connection management, with link state and
architecture of remote nodes.
rdm Shows memory used by each RTR subsystem.
rejects Displays the last rtr_mt_rejected message received by each running process.
rejhist Displays the last ten rtr_mt_rejected messages received by each running
process.
response Displays the elapsed time that a transaction has been active on the opened channels
of a process.
rfb Displays router failback operations, both a summary and detail by facility.
routing Displays statistics of transaction and broadcast traffic by facility.
rscbe Displays the most recent calls history for the RSC subsystem on a backend node.
system Displays high level summary of critical monitor pictures.
tpslo Shows transaction commits by process.
trans Displays transactions by frontend, facility, and user for each frontend, router, and
backend.
V2calls Shows RTR Version 2 system service calls.
XA 1 Displays status of XA interface activities.
1 UNIX and NT only
5.5.3 User Parsing of Monitor Output
Because of changes to many monitor screens with RTR Version 3, user scripts
that parse monitor output may need to be reviewed and changed.
5.5.4 User Customized Monitors
User monitors customized for use with RTR Version 2 may or may not work with
RTR Version 3. DIGITAL recommends that user-customized monitors be tested
with RTR Version 3 before being put into production.
System Management 5–3
