TeeJet CenterLine Quick Start Guide - Manual (Page 2)

Bulletin 98-01094
R7
Midwest Technologies Illinois, LLC
2864 Old Rochester Rd. - Springfield, IL 62703
Phone - (217) 753-8424 * Fax - (217) 753-8426
START
NEW?
RESUME?
STRAIGHT
NEW AB
EXIT
Display Item Description
Press Enter to begin real-time guidance. Run Setup prior to starting. It is assumed
that the DGPS receiver is connected to the lightbar and running properly.
Press Enter to start a new field. All vehicle trajectory data, the return to point
location, and guideline information is deleted.
Press Enter to resume work in the current field. The vehicle trajectory, return to
point location, and guideline information, stored in memory, is used for guidance
operations.
Indicates that the current guidance mode is Headland.
Press Enter to create a new reference guideline. MARK A is displayed in the text
window for approximately 5 seconds. Press Enter to mark the A location. Mark B is in
the text display. Press Enter to mark the B location.
Press Enter to begin Boundary area determination. A prompt askes for the side of
the implement that is closest to the edge of the area boundary to be traced.
Automatically or manually close the area. If an area has already been determined,
there is a VIEW item. Press Enter to view the current area.
Press Enter to exit the real-time guidance operation.
AREA
APPLY OFF?
Press Enter to turn the application off. Item then changes to Apply ON?. These menu
items only appear if no switch box or boom sense cable is being used and the
setting is set to OFF.
HEADLAND
Indicates that the current guidance mode is Straight-line.
APPLY ON?
Press Enter to turn the application on. Item then changes to Apply OFF?. These menu
items only appear if no switch box or boom sense cable is being used and the
setting is set to OFF.
CURVED
Indicates that the current guidance mode is Curved.
A+
Press Enter to shift guideline to your current position. The heading (and shape, if in
curved mode) of the original guideline is maintained, but the A/B line is shifted to the
vehicle location
LIGHTBAR
DEMO
RECEIVER
NEXT
TO START Real-time Menu
STRAIGHT
NEW AB MARK A
HEADLAND
MARK B
NEW?
RESUME?
SETUP
TOOLS
START
EXIT
RIGHT
LEFT
CLOSE
AREA
APPLY OFF? APPLY ON?
CURVE AB PATTERN
A+
LEVEL Tilt Compensation Module
must be connected
