INSTALLATION
Specifications
The 801 Flow Meter meets the following specifications:
Measuring Data
Linearity at recommened flow range +/- 3.0%
Flow Range 2-60 GPM (7.5-225 LPM)
(3-30 GPM recommened for max life)
Maximum Working Pressure 300 PSI (20.7 Bar)
Pressure Drop 10 GPM (37.85 LPM) - NA
20 GPM (75.71 LPM) - 3 PSI (0.21 Bar)
30 GPM (113.56 LPM) - 7.5 PSI (0.52 Bar)
40 GPM (151.42 LPM) - 12.5 PSI (0.86 Bar)
50 GPM (189.27 LPM) - 19.5 PSI (1.34 Bar)
60 GPM (227.12 LPM) - 29 PSI (2.0 Bar)
Measuring range is partly dependent on the selected type and size of connectors.
The flow meter is bi-directional for mounting purposes.
Electrical Data
Sensor Open collector NPN
50% square wave
10-300 Hz in operating range
Calibration Number (Approximate) TeeJet Controller 82 pulses/liter, Mid-Tech 310 pulses/gallon
LED Indicators Green-Power
Orange-Signal
Measuring Data
Body & Insert 30% glass filled polypropylene
Shaft 410 hardened stainless steel
Turbine & Bearing Support 20% talc filled polypropylene
Bearing Sapphire
Bearing Housing 303 stainless steel
Warranty
The warranty on this equipment may be affected for the following reasons:
• Improper installation
• Obvious abuse
• Lack of, or improper maintenance
• Employed in a manner inconsistent with its intended use
• Used with chemicals that are incompatible with the materials which this product is made of
(See “Warranty and Limitations” statement in your controller manual for other limitations)
This flow meter is manufactured using some or all of the following materials:
• 303 Stainless Steel
• 410 Stainless Steel
• Polypropylene
TeeJet Technologies does not recommend metering any product that reacts with these materials and damage resulting from the use of such products will not be
covered under the warranty. Please contact your chemical supplier to verify that the chemicals you are using are compatible.
If you have any questions about installation or use, refer to the installation section of your manual or call your TeeJet Technologies dealer.
