TC-Helicon Voiceprism Quickguide User Manual
Page 5
DYNAMICS AND EQ SIGNAL FLOW
EFFECTS AND MIXING SIGNAL FLOW
5
VoicePrism QuickStart Manual
Pre and Post Effects/Mixing Signal Flow
Available Processors
Compressor/Noise Gate - COMP/NG
Equalizers - EQ 1, EQ 2
SIGNAL FLOW SHOWING POTENTIAL PROCESSOR PLACEMENTS
Lighter arrows show
possible processor placements
FROM INPUT
COMP/NG
COMP/NG
COMP/NG
EQ 1
EQ 2
EQ 1
EQ 2
