Page 7

28. Hold the elbow and use a wrench to remove the rear IR

burner orifice. (See Fig. 28)

29. Replace it with the supplied NG orifice and use the six

screws removed in step 26 to secure the rear IR burner

cover and wind shield in position. Then use the two

screws removed in step 27 to secure the rear IR burner

cover and light cover in position. (See Fig. 29)

Fig. 26

Fig. 27

Fig. 25

FS388LP Natural Gas Conversion Kit Instructions

Fig. 28

Fig. 29

27. Remove the two screws securing the back IR cover and

and remove it. (See Fig. 27)

25. Use the two (2) screws removed in step 21 to secure

the bottom IR burner in position. Then place the flavor

grids and main cooking grids back in position.(See Fig.

25)

26. Remove the six screws securing the wind shield and

rear IR cover in position.(See Fig. 26)

Self-tapping screw
