Sure Heat 2008 Four Seasons FS38 Natural Gas Conversion Kit - Manual (Page 3)

FS388LP Natural Gas Conversion Kit Instructions
7. Remove the four (4) phillips pan head screws at both
sides of the the front control panel. (See Fig. 7)
8. Let a friend help you to pull the front control panel out
and hold it. Use a wrench and hold the elbow on the rear
IR burner valve then use another wrench to disconnect
the flex line. (See Fig. 8)
9. Use a wrench to disconnect the flex line from the bottom
IR burner valve. (See Fig. 9)
Phillips pan head screws
Fig. 6
Fig. 7
Fig. 8
Fig. 9
Elbow
6. Remove the self-tapping screw securing the left side
shelf in position. Loosen the four (4) hex head screws
on the left side of grill head assembly under the left side
shelf by approximately 1/2” . Then lift and take off the left
side shelf and set aside. (See Fig. 6)
5. Remove the self-tapping screw securing the right side
burner shelf in position. Loosen the four (4) hex head
screws on the right side of grill head assembly under the
side burner shelf by approximately 1/2". Then lift and
take off the side burner shelf and set aside. (See Fig. 5)
Fig. 5
self-tapping
Screw
Hex head Screws
self-tapping
Screw
Hex head Screws
Note: the other two screws located
at the same position on the left side
Flex line
Bottom IR burner valve
Flex line
