Am33 lp-p natural gas conversion instructions – Sure Heat 2008 Amana AM33 Natural Gas Conversion Kit User Manual
Page 7

25. Reinstall the igniter module in position, feed "AA" battery
with negative end in first. Connect the six igniter wires
into the six holes. (See Fig. 28)
Note: The igniter is designed in such a way that it
does not matter which terminal tab is used when
connecting igniter wires.
(See Fig. 25)
26. Angle the side burner casting and insert it into the center
hole of the side burner tray. (See Fig. 26)
27. Slide the side burner casting back in position to get the
side burner valve orifice into the side burner casting.
(See Fig. 27)
Fig. 26
Fig. 27
Fig. 25
AM33 LP-P Natural Gas Conversion Instructions
28. Use the removed two (2) phillips pan head screws in
step 5 to secure the side burner casting on the large
bracket. (See Fig. 28)
Fig. 28
29. Use the removed two (2) self-tapping screws in step 5
to secure small bracket in position. (See Fig. 29)
Fig. 29
