Superlux E205U User Manual
Page 7
TROUBLESHOOTING
Problem
Solution
Microphone sound is too
week or distorted
Windows:
Audio tab, click Volume under Record and turn up Microphone Gain Control.
Mac: From System Preferences, Choose Sound, Select Input tab and turn
up Input gain
From Control Panel, choose Sound and Audio Devices, select
Headphones are not loud
enough
Windows:
Audio tab, click Volume under Sound playback and turn up Volume Control.
Mac: From System Preferences, Choose Sound, Select Output tab and turn
up Output volume
From Control Panel, choose Sound and Audio Devices, select
No sound in headphones
Check the headphone volume control and microphone gain at
computer control panel
SPECIFICATIONS
Note: specifications are subject to change.
Type
Polar Pattern
Frequency Response
Sensitivity (at 1,000 Hz
Open Circuit Voltage)
Max. SPL
Power Requirements
Resolution
Back Elected condenser
Supercardioid
30-18,000 Hz
-38 dBV/Pa (12.6 mV)
>135 dB SPL
USB 5V, 30 mA
Up to 16 bit/48k Hz sampling rate
Finish
Champagne
silver
Connectors
Dimensions
Net
Weight
USB B-TYPE, 1/8"(3.5mm) phone connector
Ш54 Ч 150 mm (Ш2.13" Ч 5.9")
422 g (14.9 oz)
ACCESSORIES FURNISHED
OPTIONAL ITEMS
HM56 spider shockmount
13
12
HM85 pivoting
stand mount
