Superlux E205U - Manual (Page 3)

LAYOUT
Volume control: Pop-out level control to adjust
the overall volume of the Headphone output.
Headphone out connector: 1/8-inch (3.5mm)
stereo jack for connecting headphones or
studio monitors.
USB indicator: When it is lit up, it means the
USB connection is done and E205U get the
power from USB interface.
USB connector: E205U involves a USB B-type
connector, and it is allowed to connect to any
device with USB interface.
5 4
Unit: mm/inch
Through optional table stand HM6, You may put the E205U on a table and do
recording.
ON A STAND
By using a microphone stand, the E205U can be mounted on it
for recording.
CONNECTIONS
A separated 3-meter cable with USB A-type connector allowed to be
connected to a computer with USB port.
Note: Make sure to use a powered USB prot.
ON A TABLE
USB Connector
MOUNTING
c
d
c
d
1
5
0
m
m
(
5
.9
")
Ш38 (Ш1.5”)
Ш54 (Ш2.13”)
