acuna88 by Studiologic® 12
Here you may choose if an attached sustain pedal on Jack 1 is
active (On) or inactive (Off) for the zone.
In the second row you can assign a MIDI Control Change para-
meter to the pedal. All MIDI CC messages from 0 to 127 are
available. An overview of the standardised MIDI CC parameters is
given on page 54. For each zone you can assign a different MIDI
CC parameter to the pedal Jack 1.
Please note: Jack 1 is dedicated to pedals which act as on/off
switches, such as sustain pedals. Therefore the assigned MIDI CC
parameter only sends the values 0 (off ) or 127 (on).
The expression / volume pedal input, Jack 2, can also be set active
(On) or inactive (Off) for each zone.
You may assign a MIDI Control Change parameter to the pedal in
the second row. All MIDI CC messages from 0 to 127 are available.
An overview of the standardised MIDI CC parameters is given
on page 54. For each zone you can assign a different MIDI CC
parameter to pedal Jack 2.
Please note: Jack 2 is designed to accept pedals which act as
potentiometers, such as expression pedals. Therefore the MIDI CC
parameter assigned to Jack 2 will send all MIDI values from 0 to
127.
Now you’ve finished programming zone 1.
You can either store the settings or continue with the encoder
programming.
To store your settings as a preset, see page 15.
If you want to program the encoder first, please continue to page
13.
Jack 1
Jack 2
Zone programming
