Instruction Manual

2

Hardware Guide

ICUSB2321X

Rear Panel

USB type B

connector

DC Power

Input

(optional)

DC Terminal

Block Input

(optional)

DB9 Male

Port

DB9 Male

Port

USB type A

connector

ICUSB2322X

Front Panel
