Configuration
To configure the USB Serial port:
1. In the Device Manager, double-click on “Ports (COM & LPT)” to expand.
2. Right-click on the newly added serial port and select “Properties”.
3. From within the Properties window, the “Setting“ tabs offer configuration
options for the USB Serial Adapter functions:
Pinout
Pin
Signal
1
DCD
2
TxD
3
RxD
4
DTR
5
GND
6
DSR
7
RTS
8
CTS
9
RI
