StarTech.com ICUSB2324X - Manual (Page 16)

Instruction Manual
13
Specifications
ICUSB2321X ICUSB2322X ICUSB2324X
Number of Ports 1 2 4
Host Interface USB 2.0
Connectors
1 x USB type A
(male)
1 x DB9 (male)
1 x USB type B
(female)
2 x DB9 (male)
1 x DC Power
1 x 2-pin Terminal
Block
1 x USB type B
(female)
4 x DB9 (male)
1 x DC Power
1 x 2-pin Terminal
Block
Serial Protocol RS-232
Maximum Data
Transfer Rate
230 Kbps
Compatible Operating
Systems
Windows® 8 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64),
Server® 2012, 2008 R2, 2003 (32/64)
Regulatory
Certifications
CE/ FCC/ ROHS
Product Weight 33.4g 300g 593g
Product Dimensions
(LxWxH)
207.0mm x
35.0mm x
135.0mm
113.0mm x
80.0mm x
25.0mm
165.2mm x
118.0mm x
25.0mm
