Use the included jumpers and the table below, to short the pins and set your desired
RAID mode.
RAID Mode Description Short Pins
RAID 0 Striping - Improves system performance 1-2, 4-5
RAID 1
Mirror – Creates a redundant drive on the
second drive for security
2-3, 4-5
BIG
Spanning – Creates a large single drive
volume consisting of both drives.
1-2, 5-6
JBOD
Just a Bunch of Disks – Allows access to both
drives individually
(Note: A port multiplier compatible SATA
controller is required for this mode)
2-3, 5-6
Set RAID Configuration
1. Set the RAID Lock/Unlock Jumper Pins to the unlock position.
2. Using the RAID Mode setting jumper pins to your desired Mode.
3. Your RAID array has now been installed.
4. (Optional) If you would prefer to lock your RAID array so it cannot be altered by the
RAID mode setting jumper pins, power down your SATA host device, and set the
RAID Lock/Unlock Jumper Pins to the lock position.
