Instruction Manual
8
Specifications
Number of Drive Bays 4
Host Interface USB 3.0/ eSATA
Chipset ID JMicron JMB394 + JMB355 + JMS539
External Connectors
1 x USB 3.0 type B female
1 x eSATA female
1 x DIN power connector
LEDs
1 x Power
5 x Fan Speed/Mode
2 x Host Connection
4 x HDD Power/Activity
6 x RAID Mode
1 x Rebuild
1 x Hard Drive Error
Fans 1 x 80mm
Compatible Hard Drives 3.5” SATA Hard Drives
Maximum Data Transfer Rate
USB 3.0: 5 Gbps
eSATA: 3 Gbps
RAID Modes Span, 0, 1, 3, 5, 10 (1+0)
Power Adapter 12V DC, 5000mA, 4-pin DIN plug
Enclosure Material Aluminum and Plastic
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)
Humidity 5% ~ 95% RH
Dimensions 215.0mm x 126.0mm x 170.0mm
Weight 1800g
Compatible Operating Systems
Windows XP/ Server 2003/ Vista/
Server 2008 R2/ 7 (32/64-bit) / 8 (32/64-
bit) Mac OS X, Linux
