Page 3 - 10
INSTALLATION
NOTE: Be sure each cable is securely attached to its port
and that the slide latch on the AUI connector is secured to
the lock posts on the AUI port. See Figure 3-2.
To strain relief the cables for a wall-mounted FOT-F3
(Fig. 3-4):
1. Remove protective paper from one of the cable
mounts and attach the mount to the wall 3 inches
from the FOT-F3 fiber optic ports.
2. Repeat step 1 placing the other cable mount four
inches from the AUI port.
3. Strain relief each cable to its respective cable mount
by using the tie wraps.
To strain relief the cables for a FOT-F3 that is not wall-
mounted:
1. If possible, use long tie wraps to secure the FOT-F3
to a structural item such as a beam or a rafter.
2. Using additional long tie wraps, strain relief each
cable to the same structural item.
The FOT-F3 is now ready for operation. We recommend
that you test the system prior to transmitting data. Refer
to Chapter 4, Testing And Troubleshooting.
