20 | External Control
CONTROL ASSIGN
By default, the expression pedal and Hot Hand inputs are assigned to
control the TIME parameter. This can easily be changed to control any
other knob parameter or an additional REVERB SEND parameter. To as-
sign control to a knob parameter:
1. Select the desired external control option: EXP for expression pedal,
HH for Hot Hand.
2. Press and hold the CONTROL INPUT (A) button until the LED begins
to blink slowly.
3. Set the low position of the desired knob, for example MIX (B), to the
lowest setting you would like to use.
4. Press the CONTROL INPUT button again and the LED will now blink
rapidly.
5. Set the desired high position you would like to use.
6. Press the CONTROL INPUT button to complete the assignment. The
LED will blink 3 times to indicate the process is complete.
DRY WET
1 2
SPRING 2
CLUB
STAGE
ARENA
E-DOME
PLATE 1
PLATE 2
SPRING 1
MODVERB
METAL BOX ROOM
ECHO
TIME
OPTION TREBLE
MIX
HH
PRE-DELAY
(OUTPUT)
DIFFUSE
(RATE)
BASS
(DEPTH)
MIDI
EXP
CONTROL
INPUT
OPTION
SELECT
DIMENSION REVERB
A
B
