cHORUS
DUAL and QUAD: The DUAL and QUAD effect types are multi-voiced
choruses. Both produce a more animated and lavish chorus than the
CLASSIC effect type. The DUAL CHORUS has two modulating delay
signals and the QUAD has four.
FlANGER
THRU ZERO: The THRU ZERO effect type is our version of “through zero
flange” (a.k.a. tape flange). In the world of pre-recorded music this
dramatic effect is achieved when the modulating signal actually passes
through and moves ahead of the original signal—obviously, this is a
difficult feat to pull-off during a live performance (without the assistance
of a time machine). The OM achieves this effect with two delay lines.
The first is a very short, but stationary delay line, which functions as the
dry signal—the other signal modulates. As the modulating signal passes
through and moves ahead of the stationary tap we hear the classic
through zero twist (a split second of complete phase cancellation) as the
frequency response inverts.
FLANGER
CHORUS
PHASER
RESONATOR
4 STAGE
QUAD
CLASSIC
THRU
ZERO
SHADOW
RES 1
RES 2
VIBE
6 STAGE
8 STAGE DUAL
12 STAGE
Effect Types | 17
