01 : Power

The ﬁrst thing you will need is power. Your Hot Hand

™

unit comes with

4 AA

batteries to get you started. The batteries will typically last about

hours. To avoid concerns about battery life, we recommend you buy a Source
Audio

9V DC

power supply (A) (see power supply note on page

for exact

requirements).

02 : SENSOR IN connection

Next, connect the supplied

EXTENSION CABLE

to the

SENSOR IN

jack (B). Later,

you’ll plug the other end into the wire that trails from the Hot Hand, but hold
off on that for now.

03 : Guitar/Audio Connections

Now, you’ll need to make the audio connections. Plug a regular (mono)
¼-inch guitar cable from your guitar into the

GUITAR IN

jack

(C)

. Connect your

amp (or other audio device) to the

GUITAR OUT

jack, again with a regular

¼-inch cable

(D)

Note: Plugging a cable into the input will turn the unit on, causing some
of the

LED

s to light up. Don’t forget to turn off the unit by unplugging this

cord—otherwise the battery will continue to drain.

Quick Start

Your Hot Hand comes with the following components.

SAVE

(ALT) BACKPAGE

PRESET

EFFECT

(ALT) MOD SOURCE

MOTION/SPEED

PRESET

ON/OFF

ENVELOPE

CALIBRATE

LFO/SEQ

INVERT/SEQ ENABLE

DEPTH

(ALT) FREQUENCY/DELAY

HOT HAND

MOTION CONTROLLED PHASER/FLANGER

ON/OFF

SELECT

(HOLD FOR ALT MODE)

FLANGER

PHASER

FLAIL/SLOW

PICK/FAST

STRUM

Hot Hand Control Box

Hot Hand Motion Sensor

Hot Hand Extension

Hot Hand Arm Band

Hot Hand Rings (5 sizes)

4 AA Batteries

Carrying Case

Quick Start | 7
