WELCOME TO YOUR NEW MODULE!!!!!
Installation:
The Snazzy FX Dreamboat requires +/-12V to operate. It is
designed for use with the euro format modular synthesizer
system (please see)
http://www.doepfer.de/a100_man/a100t_e.htm
.
To install in your system, find 8HP of space in your euro-rack
synthesizer system, plug the 16pin power cable into the euro-
rack style power distribution board, checking the polarity so the
Blue stripe on the cable is oriented to the NEGATIVE12 volt
supply line. This is USUALLY at the bottom. Please refer to your
case manufacturers' specifications for location of the negative
supply.
