SmarTek Systems SVS-1 User Guide-Part B - Manual (Page 12)

Setting Output Example Scenario Summary (Continued)
4) BIU #1 Card file Detector/Controller Interface with 4 Relays per SVS-1 card, Slot 4 used, and 3 Phases (Line Zone Groups)
Phase 3L, Detection Delay=0 sec, Detection Extension=0, Route to Detector Channel D5
Phase 8T, Detection Delay=0 sec, Detection Extension=0, Route to Detector Channel D6
Phase 8R, Detection Delay=2 sec, Detection Extension=2, Route to Detector Channel D6
5) BIU #1 Card file Detector/Controller Interface with 2 Relays per SVS-1 card, Slot 2 used, and 3 Phases (Line Zone Groups)
Phase 3L, Detection Delay=0 sec, Detection Extension=0, Route to Detector Channel D1
Phase 8T, Detection Delay=0 sec, Detection Extension=0, Route to Detector Channel D2
Phase 8R, Detection Delay=2 sec, Detection Extension=2, Route to Detector Channel D2
6) BIU #1 SDLC Detector/Controller Interface with 3 Phases (Line Zone Groups)
Phase 5L, Detection Delay=0 sec, Detection Extension=0, Route to Detector Channel D7
Phase 2T, Detection Delay=0 sec, Detection Extension=0, Route to Detector Channel D8
Phase 2R, Detection Delay=2 sec, Detection Extension=0, Route to Detector Channel D8
