Step 14 – Slant/Fin EC-20 Assembly Instructions User Manual
Page 14
Control panel assembly – Installing sensor bulbs
14
EUTECTIC EC-20 ASSEMBLY GUIDE
- Then, insert the bulbs inside the pocket and maintain them with the spring
Detail A: Basic Control Panels
- Boiler sensor
- Safety thermostat
- Thermometer
- Contact spring (can be found in the boiler instructions bag)
- Detail B: Thermatic Control Panel
- Boiler thermostat
- Boiler sensor
- Safety thermostat
- No contact spring
Step 14
