Jaguar Caravan Multiple and Cascading Boilers 28
MODE DISPLAY DESCRIPTION & TEMPERATURE DISPLAY
Follower boiler is on stand-by mode.
Temperature display shows boiler supply water Temp.
Heating mode.
Temperature display shows boiler supply water Temp.
Frost protection mode. **
Temperature display shows boiler supply water Temp.
Lockout (Alarm) condition.
Temperature Display indicates the lockout code
Reset button must be pressed to resume normal operation.
Error Condition. *
Temperature display indicates the error code.
Warning Condition. ***
Temperature display indicates the error code.
NOTE: Blinking dot on “Mode Display” indicates active heating control, burner off.
Steady dot indicates burner is on.
*: Error must be corrected to resume boiler operation. Pressing the “Reset” button is not required.
**: The boiler loop circulator is energized, if the boiler water temperature drops below 50˚F.
***: Error must be corrected to resume DHW operation. Space heating not affected. Pressing
the “Reset” button is not required.
Table 8
FOLLOWER BOILER DISPLAY BOARD
“Boiler Operation Status”
