Mounting the 5860, Surface mounting, Flush mounting – SilentKnight 5860/5860R Remote Annunciator User Manual
Page 2
Model 5860 Installation Instructions
2
P/N 151042 Rev C
ECN 14-0358
Mounting the 5860
This section describes mounting the remote annunciator.
The annunciator can be flush- or surface-mounted.
Figure 5: Annunciator Dimensions
Surface Mounting
The Model 5860TG (gray) and 5860TR (red) trim ring kits
are available for use when surface mounting.
Figure 6: Surface Mounting
Flush Mounting
This section of the manual describes flush mounting.
Follow these steps to flush mount the 5860:
Figure 7: Flush Mounting
Mounting Holes
