Sight
16 US 06.01
6. Place the screw 58 in the frame and tighten it.
7. Use screw 66 to fix the takedown lever 25 with
the frame.
8 Sight adjustment
8.1 Sight adjustment for windage
8.1.1 Rear sight adjustment
Turning the lateral adjusting screw clockwise one
full rotation moves the point of impact
approximately 3 inches to the left at a distance of
25 yards.
Turning the lateral adjusting screw counter
clockwise one full rotation moves the point of
impact approximately 3 inches to the right at a
distance of 25 yards.
8.2 Sight adjustment for elevation
Your pistol includes two additional front sights of
different heights.
Changing to the higher front sight lowers the
point of impact approximately 7.5 inches at 25
yards.
Changing to the lower front sight raises the
point of impact approximately 7.5 inches at 25
yards.
CAUTION!
Possibly damage to the pistol
• Any adjustment to sights should only be done
on an unloaded pistol, by an armorer,
gunsmith or other qualified person.
CAUTION!
Possibly damage to the pistol when turning
the adjusting screw clockwise
• Turn the adjusting screw clockwise only until
you notice a light resistance. Do not turn the
screw any further!
• The rear sight must not exceed the edge
shown in Fig. 12.
Fig. 11
Fig. 12
!
!
