WIRE DIAGRAM
I
O
POD
TEMP/SPEED
BUSS
0-1V
TEMP
TACH
BUSS
ENCODER
HALLS
PHA
PHB
PHC
GND
HEAT HOT
NEUT
HOT
H
V
120V/
75VA
120V/
75VA
90V/
150VA
Black / Violet
Black / White
Black
Black / Yellow
Yellow
Yellow
230
120
120
N
O
N
C
C
37.0
100
Bodine
Motor
4880514
ORN
BRN
RED
DOOR SW
OSC SW
ON/OFF
7850532
1750677
TEMP DISP
1750678
RPM DISP
ELEMENT
9570893 - 120V
9570894 - 230V
OTP
CONTROL
10000J
CH
FAN
REFRIGERATION
UNIT
9990583 - 120V
9990617 - 230V
120V
N
O
N
C
C
120V
230V
230V
230V
230V
H
N
G
POWER
ON/OFF
7850532
EMI FILTER
2800502
1100505 CIRCUIT BREAKER
OR
3300501 FUSE HOLDER
SOME MODELS MAY USE FUSE HOLDERS
HOLDER: 3300501 1/120V, 2/230V.
16A: 3300513 1/120V, 2/230V REFRIG.
16A: 3300513 1/120V REFRIG.
6.3A: 3300515 2/230V.
8350509
X1000022
1750716
0860503
PART OF
REFRIGERATION
UNIT
10000J
100055 TRANSFORMER
PART OF 230V
REFRIGERATION UNIT
Chamber fan
4880527 — 120V
4880528 — 240V
‘CE’ Models
15A
15A
230V
Models
9850998
1750679
TIMER DISP
999
I
O
1750681 (SI6)
1757680 (SI4)
ALARM BOARD
TIMER SW
ON/OFF
7850532
I
O
BALLAST
4660501 — 120V
4660506 — 240V
F15-T8
4650528
FLUORESCENT LIGHT IS NOT AVAILABLE ON THE SI4
REFRIGERATION UNIT IS NOT AVAILABLE ON THE SI4
I
O
7850532
B
