Orientation, Receiving (continued), Rientation – Shellab SMO5CR-2 User Manual
Page 7
7 |
P a g e
Figure 1: Orientation Photo
RECEIVING (CONTINUED)
O
RIENTATION
Back Panel
Fuse
Holders
External Power
Outlet
Nitrogen Gas
Inlet
Permanent Connect Wire Braid
14 gauge, 6 inches (15 cm)
Intake Vent
Exhaust Vent
Control Panel
Power Switch
Intake Vent Valve
Control
Exhaust Vent Valve
Control
Outer Door
Gasket
Chamber Ceiling
Liner
Right Wall
Chamber Liner
HEPA Filter
Assembly
Left Wall
Chamber Liner
Door Latch
Door Latch
Chamber Gasket
Note: The external
power outlet type
varies by country and
voltage.
