11 | P a g e
INSTALLATION (CONTINUED)
S
HELVING
I
NSTALLATION
The horizontal airflow within the chamber moves from the HEPA filter housing on the right-hand
side of the chamber, to the large holes on the left side. Place the shelves so they do not obstruct
the duct holes on the left in order to maximize airflow across the shelf space.
1. Install shelf slide hangers on opposites of the oven by inserting the slider’s tabs into the
chamber’s mounting slots, then pushing down gently to secure the slider.
2. Hang the shelf from the two installed sliders.
Figure 2: Installed Sliding Shelf, SMO5CR-2
C LEANING
The oven interior was cleaned at the factory but not sterilized. See the Cleaning and Disinfection
topics in the User Maintenance section on page 24 for more information.
B URN I N
The SMO5CR-2 requires a burn in of its HEPA Filer. Please see the HEPA Filter Burn-In
procedure on page 17 in the Operation Sections.
